Specifications

General type
Colour printer for A4 format

Engine speed
Up to 45 pages A4 per minute in colour and b/w

Warm-up time
Approx. 20 seconds or less

Power consumption
Printing: 576.8 W; Ready mode: 11.8 W Sleep-mode: 0.4 W



PAPER HANDLING

Input capacity
Multi-purpose tray: 100 sheets (75 g/m2 equivalent), 60–220 g/m2; A4, A5, A6, B5, B6, Letter, Legal, Folio, Custom (70 x 140 to 216 x 356 mm), Banner paper up to 1220 mm.


Max. input capacity with options
2,850 sheets with 75 g/m2.

Duplex unit
Standard duplex unit; 60–163 g/m2; A4, A5, A6, B5, Letter, Legal, Custom (140 x 210 mm - 216 x 356 mm)

Output capacity
500 sheets (Equivalent to 80 g/m2) face down with paper full sensor.




PRINT FUNCTIONS

Emulations
PCL6 (5c/XL), KPDL3 (PostScript 3 compatible), PDF, XPS, Open XPS, TIFF, JPEG, URF, PWG Raster, PCLm

Fonts/barcodes
93 outline fonts (PCL6, KPDL3), 4 fonts (Calibri), 4 fonts (Cambria), 1 Bitmap font, 45 types of onedimensional barcodes, 1 type of two-dimensional barcode (PDF417)

Print features
PDF Direct Print, Internet printing IPP 1.0, E-mail printing, WSD print, secure printing IPP over TLS, Local and network authentication, Network data encryption IPsec, HTTPS, LDAP over TLS, SNMPv3, SMTP over TLS, POP over TLS, Encrypted PDF Direct Print, TLS 1.3, Secure Boot, Run-time Integrity Check, Microsoft Universal Print, Printing for Chrome OS

Operating Systems
All current Windows operating systems, MAC OS X Version 10.9 or higher, Chrome OS, Linux, as well as other operating systems on request




PAPER HANDLING OPTIONS

PF-5150 Paper feeder
Max. 550 sheet with 75 g/m2, 60 - 220 g/m², A5R - Legal, 92.1 × 165.1 (Com6), 114×162 (Youkei2), Max 4 Units

Standard universal paper cassette
550 sheet with 75 g/m2, 60–220 g/m2; A4, A5, A6, B5, B6, Letter, Legal, Folio, Custom (105 x 140 to 216 x 356 mm).

Input capacity
Multi-purpose tray: 100 sheets (75 g/m2 equivalent), 60–220 g/m2; A4, A5, A6, B5, B6, Letter, Legal, Folio, Custom (70 x 140 to 216 x 356 mm), Banner paper up to 1220 mm.




CONSUMABLES

TK-5394K
Average continuous black toner yield 18,000 pages in accordance with ISO/IEC 19798. Capacity of starter toner: Average continuous black toner yield 8,000 pages in accordance with ISO/IEC 19798.

TK-5394C
Average continuous cyan toner yield 13,000 pages in accordance with ISO/IEC 19798. Capacity of starter toner: Average continuous cyan toner yield 6,000 pages in accordance with ISO/IEC 19798.

TK-5394M
Average continuous magenta toner yield 13,000 pages in accordance with ISO/IEC 19798. Capacity of starter toner: Average continuous magenta toner yield 6,000 pages in accordance with ISO/IEC 19798.

TK-5394Y
Average continuous yellow toner yield 13,000 pages in accordance with ISO/IEC 19798. Capacity of starter toner: Average continuous yellow toner yield 6,000 pages in accordance with ISO/IEC 19798.



WARRANTY

2 years on-site as standard.



WHAT'S IN THE BOX

Main unit, initial toner, waste toner box, Quick guide, Safety Guide, Operation panel sheet , power supply cord.
